ASTM A320 Grade L7
ASTM A320 is a fastener standard defining chemical, mechanical, and heat treatment requirements for bolts & studs including carbon steel, alloy steel and stainless steel grades for low temperature & cryogenic service
Description of Material
ASTM A320 L7 is manufactured from AISI 4140 base material and is supplied in a quenched and tempered condition. Due to the impact requirements at low temperature, it is mainly used in a low temperature environment or application, predominantly but not exclusively up to 2 ½” diameter.
Lonestar can offer this material in a standard condition, or it can be provided with supplementary testing as defined in ASTM A320. This material can also be offered fully in compliance to the additional requirements of API 20E BSL 1, 2 and 3.
ASTM A320 L7
Similar or Equivalent Standards
- AISI 4142
- AFNOR 42 CD 4
- DIN 42Cr Mo4
- B.S 1506 621 Gr A
Applications
- Cold service pressure vessels
- LNG facilities
- Gas processing plants
- Heat exchangers
- Storage tanks
- Valves
- Cryogenic piping systems
- Low temp process lines
- Subsea Wellheads
Disclaimer
All information is for illustrutive purposes only.
LoneStar Group accepts no responsibility for the accuracy of data contained within or the use of any of the data by other parties. Properties do vary with the size and condition of the material.
